Descriere
System
Processor: Intel® Celeron® Quad-core Processor J6412 2.0GHz/2.6GHz
Chipset / BIOS: Intel® Elkhart Lake SoC / AMI
Storage: 2.5″ SATA III SSD 128GB
Memory: 8GB SO-DIMM, DDR4 2666MHz~3200MHz x 1 (Max 32GB, optional)
Graphics: Intel® UHD Graphics for 10th Gen Intel® Processors
Multi Monitor: 3 (# of Displays Supported) – up to 3 monitors (optional)
Expansion Slot: 1 x m.2 NVMe 1 x m.2 WiFi & Bluetooth (optional)
OS: Windows 11 IoT Enterprise LTSC 2024
Display: Primary Display Type: : 15″ WLED Backlight (Brightness: 350 cd/㎡, 1024 x 768 Resolution) * E-Series is 15.6″ FHD (16:9) Available
Touch: True-Flat Capacitive 10 Point Multi-touch
I/O Interfaces: USB: 2 x USB 2.0 (Rear Top x 2), 4 x USB 3.0(Rear Bottom x 4) : 1 x USB 2.0 (RJ11)
Serial:
· 6 (DB9 x 3, RJ50 x 2, RJ11 x 1) COM1, 3, 5: DB9(+5V on pin #9, selectable by BIOS)
· COM2, 4 (RJ50, RJ45): Support +5V and 12V(G200 only) for Special Devices and can be used for Kitchen Printer
· COM6(RJ11): USB 2.0 and RS232 with +5V/1A for Card Reader
Audio: 1 x Audio-out / 3.5mm
Secondary Display: 1 x DisplayPort (included 1 x USB 2.0 / Power Delivery +12V) *Can be used for HDMI and Standard DVI, VGA monitor by passive cable.
LAN: 1 x RJ45 (Base-T 10/100/1000 Ethernet)
Speaker (optional): 3W x 1
Peripheral Options
Secondary Display:
• LCD Type: 9.7″ or 15″ LCD (USB Port x 1)
• Touch Monitor: 9.7″ or 15″ LCD with Capacitive Touch (USB Port x 1) – by single cable(no power & USB cable)
• Standard Monitor: supported standard DP, HDMI, DVI, VGA monitor by change monitor cable)
• Standard and Powered DP MST Hub: supported standard or powered(customized) DP MST Hub.
Customer Display (CDP) :
• FSTN LCD Type (20 columns x 2 lines)
• Card Reader (MSR / SCR)
• Smart Card Reader: ISO/IEC7816 EMV Level 1 / Magnetic Stripe Reader: ISO 7811 ID-1 All tracks *Interface: USB(HID) and RS232C(COM6)
• Dallas Reader
• Dallas Reader(i-button): 6 characters / prefix and suffix *Interface: USB(HID) and RS232C(COM6)
Physical Dimension
Dimension (W x D x H): 362 x 237 x 357 (mm) / 14.2 x 9.3 x 14.0 (inch)
Weight: 4.5 (Kg) / 9.9 (lb)
Environment
Power Supply: DC 12V/5A (AC 100V~240V, 60W)
Temperature: Operating: 0 ~ 50℃ at 10% to 90% humidity
Certifications: CE, FCC, KC, CB
